Trace License for Arm (Debug Cable)
OVERVIEW
Trace License for Arm (Debug Cable)
Product number:
LA-7970X
Trace license to decode ETM traces emitted by Arm cores.
Not required to decode ETM trace emitted by a Cortex-M core.
Usually only required for on-chip trace, as the tools for
off-chip trace usually include a trace license already.
Please add the base serial number of your existing debug cable
or CombiProbe to your order.
Product Details
Technical Information
INCLUDES:
Programmable To:
The License can be added to one of the following products.
- LA-3743A Debugger for Armv8/Armv9-A/R Add.
- LA-3250 Debugger Arm7 IDC20A (PACK)
- LA-7742 JTAG Debugger for Arm9
- LA-3253 Debugger for Armv7-A/R IDC20A (PACK)
- LA-4591 Package CombiProbe 2 MIPI60-Cv2 Long
- LA-3256 Debugger for Armv8/Armv9 via SSDP (PACK)
- LA-3251 Debugger Arm9 IDC20A (PACK)
- LA-4572 CombiProbe 2 Hardware
- LA-4590 Package CombiProbe 2 MIPI60-Cv2
- LA-7746A JTAG Debugger License for Arm7 Add.
- LA-4595 Package CombiProbe 2 Intel® DCI OOB
- LA-7843 Debugger for Cortex-A/R (Armv7 32-bit)
- LA-7742A JTAG Debugger License for Arm9 Add.
- LA-7843A Debugger for Armv7-A/R Add.
- LA-3255 Debugger for Armv8/Armv9-A/R IDC20A (PACK)
- LA-7765 JTAG Debugger for Arm11 (ICD)
- LA-2762 Package for CombiProbe 2 dsPIC Dual Core
- LA-4502 CombiProbe ARM-Debugger and 4-Bit Trace
- LA-3252 Debugger Arm11 IDC20A (PACK)
- LA-7744 JTAG Debugger for ARM10 (ICD)
- LA-7765A JTAG Debugger License for Arm11 Add.
- LA-3743 Debugger for Cortex-A/R (Armv8 and Armv9)
- LA-7746 JTAG Debugger for Arm7 20 Pin Connector (ICD)
Add-ons
Extend the Trace License for Arm (Debug Cable)
Allowed Licenses
The following licenses can be added to the product to support debug and/or tracing of other core architectures.
